Dettagli del prodotto
Luogo di origine: Jiangsu, Cina
Marca: HUADING
Termini di trasporto & di pagamento
Quantità di ordine minimo: 1 INSIEME
Prezzo: $18,000 / set
|
video outgoing-inspection:
|
Provided
|
machinery test report:
|
Provided
|
core components:
|
bowl
|
warranty:
|
1 Year
|
productivity:
|
/
|
weight (kg):
|
2000 kg
|
Bowl diameter:
|
186 - 720 mm
|
L/D:
|
3.0 - 5.5
|
Bowl speed:
|
2000 - 6000 rpm
|
G-forcee:
|
1600 - 4000 g
|
Weight:
|
600 - 8000 Kg, 1200
|
Primary motor:
|
5.5 - 132 Kw
|
Secondary motor:
|
2.2 - 45 Kw
|
Material:
|
EN 1.4462 / 1.4362 / 1.4410 / 1.4501 / AISI 304 / 316 / 316L
|
Noise:
|
< 88 dB
|
Product Keywords:
|
olive oil lw 180 decanter centrifuge
|
Condition:
|
New
|
Applicable Industries:
|
Construction works , Energy & Mining, Food & Beverage Factory, Manufacturing Plant
|
Showroom Location:
|
Canada, Germany, South Africa, United States
|
Marketing Type:
|
New Product 2022
|
Warranty of core components:
|
5 Years
|
|
video outgoing-inspection:
|
Provided
|
|
machinery test report:
|
Provided
|
|
core components:
|
bowl
|
|
warranty:
|
1 Year
|
|
productivity:
|
/
|
|
weight (kg):
|
2000 kg
|
|
Bowl diameter:
|
186 - 720 mm
|
|
L/D:
|
3.0 - 5.5
|
|
Bowl speed:
|
2000 - 6000 rpm
|
|
G-forcee:
|
1600 - 4000 g
|
|
Weight:
|
600 - 8000 Kg, 1200
|
|
Primary motor:
|
5.5 - 132 Kw
|
|
Secondary motor:
|
2.2 - 45 Kw
|
|
Material:
|
EN 1.4462 / 1.4362 / 1.4410 / 1.4501 / AISI 304 / 316 / 316L
|
|
Noise:
|
< 88 dB
|
|
Product Keywords:
|
olive oil lw 180 decanter centrifuge
|
|
Condition:
|
New
|
|
Applicable Industries:
|
Construction works , Energy & Mining, Food & Beverage Factory, Manufacturing Plant
|
|
Showroom Location:
|
Canada, Germany, South Africa, United States
|
|
Marketing Type:
|
New Product 2022
|
|
Warranty of core components:
|
5 Years
|
| Diametro della scodella | 186 - 720 mm |
| L/D | 3.0 a 5.5 |
| Velocità della scodella | 2000 - 6000 giri/min |
| Forza G | 1600 - 4000 g |
| Peso | 600 - 8000 kg |
| Motore primario | 5.5 - 132 Kw |
| Motore secondario | 2.2 - 45 Kw |
| Materiale | EN 1.4462 / 1.4362 / 1.4410 / 1.4501 / AISI 304 / 316 / 316L |
| Noise | < 88 dB |
| Indicatore della ciotola (mm) | Velocità della vasca (rpm) | L/D | Forza G | Capacità (m3/h) | Eliminazione dei solidi (m3/h) | Motore primario (Kw) | Peso (kg) | Dimensione (mm) |
|---|---|---|---|---|---|---|---|---|
| 250 | 4800 ~ 5400 | 3.0~5.0 | 2000~3500 | 3 ~ 5 | 0.4 | 11 | 760 | 1600×1100×850 |
| 300 | 4200~4600 | 3.0~5.0 | 2000~3500 | 3 ~ 15 | 0.8 | 11 ~ 15 | 1500 | 2470×1230×850 |
| 350 | 3700~4200 | 3.0~5.0 | 2000~3500 | 5 ~ 20 | 1.2 | 5 ~ 22 | 2000 | 2790×1300×880 |
| 400 | 3200~3900 | 3.0~4.8 | 2000~3500 | 5 ~ 30 | 2 | 18.5 ~ 30 | 2600 | 2950×1400×850 |
| 450 | 3000 ~ 3700 | 3.0~5.0 | 2000~3500 | 5 ~ 45 | 2.5 | 22~37 | 3200 | 3300 × 1500 × 920 |
| 530 | 2700~3450 | 3.0~5.0 | 2000~3500 | 10~80 | 5 | 30 ~ 55 | 5200 | 3730×1600×1100 |
| 580 | 2600 ~ 3300 | 3.0~5.0 | 2000~3500 | 10 ~ 90 | 6 | 45 ~ 75 | 6900 | 4000×1400×1600 |
| 650 | 2400 ~ 3100 | 3.0~5.0 | 2000~3500 | 20~105 | 8 | 37 ~ 90 | 8200 | 4300 × 1900 × 1350 |
| 760 | 2200~2900 | 3.0~5.0 | 2000~3500 | 30 ~ 120 | 12 | 55~135 | 12000 | 5000×2500×1500 |
| 900 | 1800 ~ 2600 | 3.0~5.0 | 2000~3500 | 40~180 | 16 | 75~160 | 18000 | 6500 × 2700 × 1500 |
