Customized Glycerin Centrifuge of CE Standard

Product Details

Place of Origin: Jiangsu, China

Brand Name: HUADING

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: $20,000-25,000 / set

Get Best Price

Chat Now

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    customized disc centrifuge, customized disc stack separator, ce disc centrifuge


Product Type:	Other	Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided	Core Components:	Bowl
Voltage:	110 - 415V	Power(w):	4 - 90 Kw
Dimension(lwh):	200012001800mm	Warranty:	1 Year
Key Selling Points:	/	Capacity:	4000
Weight (KG):	2500	Setting Speed:	6000
After-sales Service Provided:	Overseas Service Center Available	Drive:	Gear / Belt
Bowl Speed:	4000 - 10000 Rpm	Centrifugal Force:	> 10,000 G
Bowl Volume:	8 - 300 L	Bowl Weight:	50-15000 Kg
Solids Holding Space:	2 - 50 L	Inlet Pressure:	0-0.1 Mpa
Liquid Outlet Pressure:	0.2-0.6 Mpa	Starting Time:	5 - 30 Mins

Product Type:	Other
Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided
Core Components:	Bowl
Voltage:	110 - 415V
Power(w):	4 - 90 Kw
Dimension(lwh):	200012001800mm
Warranty:	1 Year
Key Selling Points:	/
Capacity:	4000
Weight (KG):	2500
Setting Speed:	6000
After-sales Service Provided:	Overseas Service Center Available
Drive:	Gear / Belt
Bowl Speed:	4000 - 10000 Rpm
Centrifugal Force:	> 10,000 G
Bowl Volume:	8 - 300 L
Bowl Weight:	50-15000 Kg
Solids Holding Space:	2 - 50 L
Inlet Pressure:	0-0.1 Mpa
Liquid Outlet Pressure:	0.2-0.6 Mpa
Starting Time:	5 - 30 Mins

Customized Glycerin Centrifuge of CE Standard

As the leading manufacturer of disc separators in China since 1954, Huading Separator specializes in customized centrifuges that meet CE standards for various industrial applications.

Technical Specifications

Specification	Details
Drive	Gear / Belt
Bowl Speed	4000 - 10000 rpm
Centrifugal Force	> 10,000 g
Bowl Volume	8 - 300 L
Bowl Weight	50-15000 Kg
Solids Holding Space	2 - 50 L
Inlet Pressure	0-0.1 Mpa
Liquid Outlet Pressure	0.2-0.6 Mpa
Starting Time	5 - 30 mins
Stopping Time (no brakes)	> 40 mins

Company Overview

Huading Separator has over 60 years of tradition in mechanical separating technology. As China's leading manufacturer, our developments serve diverse industries including beverage and dairy processing, oil and fat recovery, chemicals, pharmaceuticals, biotechnology, starch technology, marine engineering, energy, oil fields, and environmental technology. We develop and build customized centrifuges and can supply complete process lines as required.

Compliance Standards

JB/T 8103 standards - Chinese national standard of disc centrifuge
2006/42/EC (Machinery)
2014/35/EU (Low Voltage)
2014/30/EU (Electromagnetic Compatibility)
Quality management system of ISO9001-2000

Centrifugal Separation Technology

The disc stack separator uses extremely high centrifugal forces to separate solids and one or two liquid phases in a single continuous process. Denser solids are forced outward against the rotating bowl wall while less dense liquid phases form concentric inner layers. The interface position between phases can be adjusted for maximum efficiency. Special plates (the "disc stack") provide additional surface settling area, dramatically speeding up separation. This configuration enables continuous separation of various solids from one or two liquids, with solids removal occurring continuously, intermittently, or manually depending on application requirements.

2-Phase Separation Disc Stack Centrifuge

Process Flow:
1. Feed
2. Discharge
3. Inlet tube
4. Disc stack
5. Solids holding space
6. Centripetal pump chamber
7. Centripetal pump

Separation occurs inside a rotating bowl where feed is introduced via a stationary inlet pipe and accelerated in the distributor before entering the disc stack. Liquid-solids separation takes place between discs, with liquid moving through the disc stack to the center and pumped out via a built-in paring disc. Solids collect in the periphery and discharge intermittently through a hydraulic system that opens solids ports at preset intervals.

3-Phase Separation Disc Stack Centrifuge

Process Flow:
1. Inlet tube
2. Central bore
3. Distributor
4. Distributor bore
5. Rising channels
6. Light phase centripetal pump
7. Heavy phase centripetal pump

Suspension enters the separator bowl through a feeding pipe into the disc stack. Heavy phase and sludge move toward the bowl periphery while light phase flows toward the center for pumping. Heavy phase is led over a top disc into a chamber for pumping out. Solids collect in the sludge space and discharge intermittently via hydraulic system, then exit through a cyclone.

Self-cleaning disc stack centrifuges are categorized as purifiers (for solids and two liquid phases) or clarifiers (for solids and one liquid phase).

Why Choose Huading Separator

Our Advantages

Huading Separator is a market leader in centrifugal separating technology with over 60 years of experience developing and manufacturing centrifugal separation equipment.

60+ Years

Experience developing and manufacturing disc stack centrifuges

40000+

Installations in more than 50 countries since 1954

100+

Centrifuge models to satisfy diverse customer demands

Global

References from well-known food and pharmaceutical manufacturers
