Textile Dyeing Sludge Dewatering Decanter Centrifuge Automatic Flocculation Dosing System 10m3/H

The LW450 textile dyeing sludge dewatering decanter centrifuge provides a complete automatic solution for the highly variable sludge produced by textile printing and dyeing wastewater plants. Dye house effluent contains residual dyestuff, sizing agents, surfactants, heavy metals from certain dye classes and large quantities of suspended solids that are difficult to settle. After chemical coagulation and dissolved air flotation, the resulting sludge remains thixotropic and compressible, which makes conventional filter presses slow and labor intensive. This decanter centrifuge, combined with an automatic flocculation dosing system, continuously thickens and dewaters such sludge to a stackable cake with minimum operator attention.

The complete system comprises a polymer preparation and dosing skid, a sludge feed pump and the LW450 centrifuge controlled by a PLC that monitors feed flow, polymer dosage, torque and differential speed. When sludge consistency changes, the control system automatically adjusts the back drive to maintain constant cake dryness and liquid clarity. Because dyeing sludge often contains aggressive chemicals, the machine can be supplied with SS316L bowl and conveyor, and all external surfaces are painted with an epoxy system resistant to humid, chemically loaded atmospheres typical of textile parks.

• Automatic flocculation dosing: PLC controlled polymer make down and dosing unit adapts chemical feed to sludge quality for stable floc formation.
• Self optimizing control: torque based control logic adjusts differential speed automatically, keeping cake discharge consistent around the clock.
• High capture rate: advanced pool depth design retains fine dye house flocs, producing clear effluent that can be returned to the treatment headworks.
• Corrosion resistant option: SS316L wetted parts withstand acidic and alkaline cleaning chemicals used in textile wastewater neutralization.
• Compact footprint: machine, dosing unit and control panel fit into a small area, simplifying retrofit into existing sludge rooms.
• Low noise operation: vibration isolated frame and sound dampening covers keep noise below 85 dB at one meter.

The system is designed for centralized textile industrial parks, denim washing plants, printing and dyeing mills, carpet manufacturers and any facility treating high strength colored wastewater. It dewaters chemical sludge from coagulation settling, DAF float sludge and biological excess sludge, reducing moisture so the cake can be disposed of in sanitary landfills or fed to incinerators. With the dosing unit operating automatically, one supervisor can manage several decanters, which substantially lowers labor cost compared with plate and frame filter presses.

Each LW450 system is fully assembled, piped and tested in our factory, including a trial run with water and a simulated sludge load to verify vibration, temperature and noise levels. The equipment is shipped in export grade wooden cases with the control cabinet protected by moisture proof packaging. Technical documentation covers the mechanical drawing, electrical diagrams, PLC program description, operating manual and recommended spare parts. We provide 12 months warranty, free replacement of defective parts and lifetime technical support by phone, email or remote connection.
