Product Details
Place of Origin: Liaoning, China
Brand Name: WNRLN
Certification: ISO 9001:2015, CE, CCS Type Approval
Model Number: DOS-400F
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: USD 22,000 - 42,000 / Set
Packaging Details: Seaworthy export wooden crate with VCI anti-corrosion wrap, desiccant packs, and shock-proof cushioning
Delivery Time: 35-50 working days after deposit
Payment Terms: T/T,L/C
Supply Ability: 25 Sets per Month
|
Bowl Diameter:
|
400mm
|
Bowl Speed:
|
6800 RPM
|
Capacity HFO:
|
2000-3500 L/H
|
Capacity MGO:
|
4000-6000 L/H
|
Motor Power:
|
15 KW
|
Discharge Method:
|
Automatic Total Discharge
|
Motor Protection:
|
IP56
|
Classification:
|
CCS Type Approved
|
|
Bowl Diameter:
|
400mm
|
|
Bowl Speed:
|
6800 RPM
|
|
Capacity HFO:
|
2000-3500 L/H
|
|
Capacity MGO:
|
4000-6000 L/H
|
|
Motor Power:
|
15 KW
|
|
Discharge Method:
|
Automatic Total Discharge
|
|
Motor Protection:
|
IP56
|
|
Classification:
|
CCS Type Approved
|
This marine-grade disc oil separator is specifically designed for fuel oil purification on commercial vessels, handling both heavy fuel oil (HFO) and marine gas oil (MGO) treatment. The self-cleaning bowl continuously removes water, catalytic fines (cat fines), and asphaltenic sludge from bunker fuel, protecting main engine fuel injection systems and ensuring compliance with engine manufacturer warranty requirements. CCS (China Classification Society) certified, with optional DNV, BV, and ABS approvals available for international flag vessels.
| Parameter | Value |
|---|---|
| Bowl Diameter | 400mm |
| Bowl Speed | 6800 RPM |
| Capacity (HFO 380cSt) | 2000-3500 L/H |
| Capacity (MGO) | 4000-6000 L/H |
| Motor Power | 15 kW |
| Discharge Method | Automatic Total Discharge |
| Classification Approval | CCS (DNV, BV, ABS optional) |
| Motor Protection | IP56 |
| Heating Jacket | Steam/Electric (optional) |
